- General Information
- Manufacturer
- HPE Sourcing
- Manufacturer Website Address
- https://imaginenext.ingrammicro.com/sourcing-and-certified-pre-owned
- Brand Name
- Aruba
- Product Series
- CX 6200
- Product Type
- Ethernet Switch
- Technical Information
- Features
- Intelligent monitoring
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Uplink Port
- Yes
- Modular
- Yes
- Stack Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet PoE
- 4 x Gigabit Expansion Slot
- 1 x USB-C Console Port
- 1 x RJ-45 Console Port
- 1 x OOBM Port
- 1 x USB Type-A Host Port
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 1000Base-X
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Expansion Slot Type
- SFP (mini-GBIC)
- Number of SFP Slots
- 4
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.3
- IEEE 802.3az
- IEEE 802.3ad
- IEEE 802.1s
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.1ab
- IEEE 802.1Q
- IEEE 802.1v
- IEEE 802.1x
- IEEE 802.1ae
- IEEE 802.1ak
- IEEE 802.1t
- IEEE 802.3ab
- IEEE 802.3ae
- IEEE 802.3bz
- IEEE 802.3x
- IEEE 802.3z
- IEEE 802.3at
- IEEE 802.3af
- IEEE 802.3bt
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 370 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- AC
- PoE+
- Number of Power Supplies Installed
- 1
- Power Consumption
- 76 W
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Cabinet Mount
- Surface Mount
- Height
- 1.7"
- Width
- 17.4"
- Depth
- 12.9"
- Weight (Approximate)
- 11.24 lb
- Miscellaneous
- Application/Usage
- Enterprise
- Branch Office
- Campus
- Network
- Certifications & Standards
- EN 62368-1:2014 +A11:2017
- EN 62368-1:2020 +A11:2020
- BS EN 62368-1:2014 + A11:2017 2nd Ed BS
- EN 62368-1:2020 + A11:2020 3rd Ed
- UL 62368-1, 3rd Ed
- CAN/CSA C22.2 No. 62368-1:19, 3rd Ed.
- IEC 62368-1:2014 2nd Ed
- IEC 62368-1: 2018 3rd Ed.
- CNS-15598-1:2020
- GB 4943.1:2022
- EN 55032:2015 +A11:2020, Class A
- EN 61000-3-2:2019
- EN 61000-3-3:2013
- FCC 47 CFR part 15B: Class A
- ICES-003 Issue 7: 2020, Class A
- VCCI-CISPR 32, Class A
- CISPR 32: 2016, Class A
- AS/NZS CISPR 32: 2015, Class A GB/T 9254.1-2021, Class A CNS 15936: 2020, Class A KS C 9832
- EN 60825-1:2014/IEC
- 60825-1:2014 Class 1
- Class 1 Laser Products/Laser Klasse 1
- CISPR 35: 2016
- EN 55035:2017 +A11:2020
- IEC 61000-4-2
- IEC 61000-4-3
- IEC 61000-4-4
- IEC 61000-4-5
- IEC 61000-4-6
- IEC 61000-4-8
- IEC 61000-4-11
- IEC / EN 61000-3-2
- IEC / EN 61000-3-3
- EN 63000:2018/IEC 63000:2018
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
