- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- TP-Link
- Product Line
- Omada
- Product Type
- Ethernet Switch
- 48× Gigabit RJ45 ports and 4× Gigabit SFP slots
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, and IGMP Snooping
- ERPS supports rapid protection and recovery in a ring topology
- Fanless design for silent operation
- Durable metal casing and rackmountable design
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
- Technical Information
- Features
- Zero-Touch Provisioning (ZTP)
- Fanless
- DHCP Relay
- DHCP Snooping
- Broadcast Storm Control
- Remote Monitoring (RMON)
- Support Dual Image
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 1 × RJ-45 Console Port
- 1 × Micro-USB Console Port
- 4 x Gigabit Ethernet SFP Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 1000Base-X
- Maximum Data Transfer Rate
- 128 MB/s
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Expansion Slot Type
- SFP
- Number of SFP Slots
- 4
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.1p
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.1ab
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- No
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- AC
- Power Consumption
- 34.86 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 8.7"
- Miscellaneous
- Application/Usage
- Network
- Wireless Access Point
- Traffic
- Security
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
