The 24" NEC MultiSync® EA242WU is widescreen WUXGA desktop monitor ideal for corporate environments. Designed for excellent imaging and ideal for multiple monitor configurations, this widescreen model features IPS panel technology with wide viewing angles (178° horizontal/vertical) and ergonomic adjustability. The LED backlighting of the EA242WU allows for a slimmer profile, lighter weight and increased power savings compared to previous generation models. Smart sensing technology automatically detects your work conditions to determine the proper display brightness with ambient light and human sensors. Full-featured connectivity including HDMI, DisplayPort 1.4 in / out, 2-port USB 3.1 hub, USB Type-C PD and LAN connects users to the latest peripherals and future-proofs the investment.
- LED backlight technology provides for industry-leading low power consumption and less hazardous materials
- Height-adjust, pivot, tilt and swivel capabilities add flexibility and comfort to your viewing preferences
- Full connectivity, including DisplayPort in / out, HDMI 1.4, USB Type-C PD and LAN
- Touch-sensitive OSD® controls are integrated into the bezel, making display adjustments easier than ever
- Human and ambient light sensors automatically detect your work conditions to determine the proper display brightness, thereby conserving power
- ECO Mode™ allows you to manually adjust the display's brightness to your liking, saving power and reducing your energy costs
- Dual direction pivot and the image flip feature allow users to arrange the thinnest inactive areas together for nearly seemless images
- NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
- compatible with Low Blue Light and Flicker-Free
Ambix® Allows up to two inputs (VGA and DVI-I) to be connected to a single monitor and for each of the three signals to be displayed with the press of a button.
No Touch Auto Adjust™ Allows the monitor to be automatically adjusted to optimal image settings when initially turned on.
Rapid Response™ Delivers virtually uninterrupted, undistorted viewing of high-speed, full-motion video.
Ambient Light Sensor Automatically adjusts the backlight and power management depending on the ambient lighting brightness.
Human Sensor Monitors the presence of a user in front of the display and can go into power saving mode if the user leaves, saving up to 99% power
LED Backlight Provides for industry-leading low power consumption and less hazardous materials.
Kensington Lock Enables a security cable to be attached to the projector.
- General Information
- Manufacturer
- Sharp
- Manufacturer Website Address
- http://www.sharp-nec-displays.com/
- Brand Name
- NEC Display
- Product Line
- MultiSync
- Product Type
- LCD Monitor
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Number of Screens
- 1
- Screen Size Class
- 24"
- Viewable Screen Size
- 24.1"
- Screen Mode
- WUXGA
- Panel Technology
- In-plane Switching (IPS) Technology
- Response Time
- 6 ms
- Aspect Ratio
- 16:10
- Pixel Pitch
- 10.6 mil
- Horizontal Viewing Angle
- 178°
- Vertical Viewing Angle
- 178°
- Backlight Technology
- LED
- HDCP Supported
- Yes
- Features
- Cable Lock Slot
- Low Blue Light
- Flicker-free
- Wide Viewing Angle
- Ergonomic Design
- sRGB
- Eco Mode
- Carbon Footprint Meter
- Carrying Handle
- XtraView
- On-screen Display (OSD)
- Cable Management
- Plug & Play
- Horizontal Frequency
- 31.50 kHz to 77 kHz
- Vertical Frequency
- 50 Hz to 60 Hz
- Stand Adjustments
- Height
- Pivot
- Swivel
- Tilt
- Video
- Maximum Resolution
- 1920 x 1200
- Standard Refresh Rate
- 60 Hz
- Color Supported
- 16.7 Million Colors
- Native Contrast Ratio
- 1,000:1
- Brightness
- 300 Nit
- Color Gamut
- 73.1% NTSC
- 99.8% sRGB
- Audio
- Speakers
- Yes
- Interfaces/Ports
- Network (RJ-45)
- Yes
- HDMI
- Yes
- USB
- Yes
- DisplayPort
- Yes
- USB Type-C
- Yes
- Number of USB Ports
- 2
- Built-in Devices
- Built-in Devices
- USB Hub
- Power Description
- Operating Power Consumption
- 19 W
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 100 x 100
- Color Family
- Black
- Color
- Black
- Height
- 13.7"
- Width
- 20.9"
- Depth
- 1.9"
- Height with Stand
- 20.29"
- Width with Stand
- 20.93"
- Depth with Stand
- 9.84"
- Weight (Approximate)
- 9.26 lb
- Weight with Stand (Approximate)
- 14.77 lb
- Miscellaneous
- Package Contents
- MultiSync EA242WU-BK Widescreen LCD Monitor
- Setup sheet
- User manual
- Power cord
- DisplayPort cable
- USB cable
- Energy Star
- Yes
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- ENERGY STAR 8.0
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
