- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- Aruba
- Product Series
- CX 8100
- Product Type
- Layer 3 Switch
High-performance 1.76Tbps of bi-directional switching and 1,309 Mpps of forwarding designed for aggregation in the campus or top-of-rack in data center environments.
Four different base models, each sold in bundles that support two airflow modes (Front to Back, and Back to Front) with Advanced Layer 2/3 feature set that includes BGP, OSPF, VRF, and IPv6.
High availability with industry-leading VSX redundancy and redundant power supplies and fans.
Aruba AOS-CX automation and programmability using built-in REST APIs and Python scripts with intelligent monitoring and visibility delivered by the Aruba Network Analytics Engine.
Modular Cloud-Native Architecture
HPE Aruba Networking CX 8100 Switch Series features AOS-CX which simplify the complexities of managing data center networks with automation options to match your IT organization's operating model.
Proactively detect issues and speed troubleshooting with actionable insights provided by an analytics engine embedded in every switch. Always-on infrastructure designed for resiliency and upgrades with zero downtime.
REST APIs and Python scripting provide fine-grained microservices architecture enabling full integration with other workflow systems and services.
Continual state synchronization provides superior fault tolerance and high availability. Always-on infrastructure designed for resiliency and upgrades with zero downtime.
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- High Availability Supported
- Yes
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 24 x /1/2.5/5/10BASE-T Gigabit Ethernet RJ-45 Network Port
- 4 x 1/10 Gigabit Ethernet SFP+ Expansion Slot
- 4 x 40/100 Gigabit Ethernet QSFP28 Expansion Slot
- 1 x RJ-45 Serial Port
- 1 x USB-C Console Port
- 1 x RJ-45 Ethernet Port
- 1 x USB-Type A Port
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- 2.5 Gigabit Ethernet
- 5 Gigabit Ethernet
- 10 Gigabit Ethernet
- 40 Gigabit Ethernet
- 100 Gigabit Ethernet
- Network Technology
- 1000Base-T
- 2.5GBase-T
- 5GBase-T
- 10GBase-T
- 1000Base-X
- 10GBase-X
- 40GBase-X
- 100GBase-X
- Maximum Data Transfer Rate
- 12.50 GB/s
- I/O Expansions
- Total Number of Expansion Slots
- 8
- Expansion Slot Type
- SFP
- SFP+
- QSFP
- QSFP28
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.1ab
- IEEE 802.1ak
- IEEE 802.1AX
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.1s
- IEEE 802.1t
- IEEE 802.1v
- IEEE 802.1w
- IEEE 802.3ab
- IEEE 802.3ad
- IEEE 802.3ae
- IEEE 802.3an
- IEEE 802.3ba
- IEEE 802.3by
- IEEE 802.3x
- IEEE 802.3z
- Management & Protocols
- Manageable
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Power Consumption
- 400 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Compact
- Miscellaneous
- Package Contents
- CX 8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 BF 3Fan 2AC PSU Sw Bdl
- 2 x Power Supplies
- 2 x Post Rack Kit
- 3 x Fan Tray
- Application/Usage
- Campus
- Data Center
- Network
- IoT Devices
