- General Information
- Manufacturer
- GIGABYTE Technology, Inc
- Manufacturer Website Address
- http://www.gigabyte.us
- Brand Name
- Gigabyte
- Product Type
- Graphic Card
CORE CLOCK
2587 MHz (Reference card :2572 MHz)
The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
Built for Mega Geometry
AI-Enhanced Graphics and Performance
NVIDIA DLSS 4 with Multi Frame Generation
Game-Winning Responsiveness
NVIDIA Reflex 2 with Frame Warp
True-to-Life Graphics
Full ray tracing with neural rendering
Digital Humans and AI Assistants
NVIDIA ACE
Accelerate Your Creativity
NVIDIA Studio creator tools and technology
Enhance Any Video with AI
NVIDIA Broadcast and ninth-gen NVIDIA Encoder
Performance and Reliability
NVIDIA app with Game Ready and Studio Drivers
The Ultimate Gaming Display Technologies
NVIDIA G-SYNC
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a copper plate, 3D active fans, and screen cooling.
HAWK FAN
The Hawk Fan features a unique blade design inspired by the aerodynamics of an eagle's wing. This design reduces air resistance and noise levels, resulting in up to a 53.6% increase in air pressure and a 12.5% increase in air volume without compromising acoustics.
- Technical Information
- API Supported
- DirectX 12
- OpenGL 4.6
- Number of Monitors Supported
- 4
- Features
- Dual-fan Cooler
- Maximum Digital Display Resolution
- 7680 x 4320
- CUDA Cores
- 4608
- AI-powered
- Yes
- Processor & Chipset
- Chipset Manufacturer
- NVIDIA
- Chipset Line
- GeForce
- Chipset Series
- RTX
- Chipset Model
- RTX 5060 Ti
- GPU Clock
- 2.59 GHz
- Memory
- Standard Memory
- 16 GB
- Memory Technology
- GDDR7
- Bus Width
- 128 bit
- Interfaces/Ports
- Host Interface
- PCI Express 5.0
- DisplayPort
- Yes
- Number of DisplayPort Outputs
- 3
- HDMI
- Yes
- Number of HDMI Outputs
- 1
- Power Description
- Power Supply Wattage
- 650 W
- Power Connector
- 1x 8-pin
- Physical Characteristics
- Form Factor
- Plug-in Card
- Cooler Type
- Active Cooler
- Height
- 1.6"
- Width
- 4.7"
- Length
- 8.2"
- Miscellaneous
- Platform Supported
- PC
