The AirborneM2M™ line of industrial wireless access points is built for networking equipment in an array of machine-to-machine (M2M) applications. AirborneM2M™ Access Point features industrial strength packaging and support a wide temperature rating (-40° to 85°C) to withstand challenging M2M environments. Power options include 5-36VDC input or PoE 802.3af (Power over Ethernet) on select models.
Combination Access Point and Client Capability
The AirborneM2M™ Access Point enables M2M equipment to create a self sufficient Wi-Fi network and easy access to equipment data or resources from WiFi enabled devices. The product also has the capability to be switched from an access point to a client; supporting both a single or dual RS-232/422/485 serial ports or a single 10/100 Mbps Ethernet port. The Ethernet port can be placed into either a router or bridge mode.
- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- B+B SmartWorx
- Product Type
- Wireless Access Point
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Wireless LAN Standard
- IEEE 802.11n
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Minimum Frequency
- 2.40 GHz
- ISM Maximum Frequency
- 2.48 GHz
- UNII Minimum Frequency
- 5.15 GHz
- UNII Maximum Frequency
- 5.83 GHz
- Antenna Gain (Isotropic)
- 2 dBi
- Antenna Type
- Omnidirectional Antenna
- Antenna Connector
- RP-SMA Connector
- Wireless Transmission Speed
- 65 Mbit/s
- Wireless Security
- 64/128-bit WEP
- WPA-PSK (TKIP)
- WPA2-PSK (AES)
- IEEE 802.1x (EAP)
- WPA-Enterprise
- WPA2-Enterprise
- EAP-TLS/MSCHAPv2
- EAP-TTLS/MSCHAPv2
- EAP-TTLS (MD5)
- EAP-PEAPv0/MSCHAPv2
- LEAP
- Interfaces/Ports
- Ethernet Technology
- Ethernet
- Fast Ethernet
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-11)
- No
- PoE (RJ-45) Port
- No
- VGA
- No
- HDMI
- No
- Audio Line Out
- No
- Serial Port
- Yes
- USB
- No
- Powerline
- No
- Power Description
- Input Voltage
- 5 V DC
- Physical Characteristics
- Form Factor
- Rail-mountable
- Panel-mountable
- Height
- 1.2"
- Width
- 4.9"
- Depth
- 4.7"
- Weight (Approximate)
- 1.05 lb
- Miscellaneous
- Certifications & Standards
- FCC Part 15.247, Class B Sub C Modular Approval
- Industry Canada RSS-210
- CE
- ETSI EN300-328 v1.7.1
- ETSI 60950-1
- Directive 2004/108/EC
- ETSI EN 55022:2006 + A1:2007 (emissions)
- ETSI EN 55024:1998 + A1:2001
- ETSI EN 55024:1998 + A2:2003 (immunity)
- FCC Part 15 Subpart B:2007
- Part 15.107(b) (conducted emissions, Class A)
- Part 15.109(g) (radiated emissions, Class B)
- Industry Canada ICES-003:2004, Issue 4
- AS/NZS CISPR 11:2004 (Australia/New Zealand)
- Country of Origin
- United States
- Environmentally Friendly
- Yes
